Paper: CVPR 2022 [Link]

This note is generated by claude code when I go through published code to understand the algorithm introduced in paper.

Thinking Problem: how to convert this RePainting algorithm to the tabular data, considering the In-Context learning paradigm, where we take the tabular input data as a 2-D images, where pixel is the feature cell.

Notation Reference

Symbol	Meaning
$x^g$	Clean ground truth image (no noise)
$m$	Binary mask (1=keep, 0=inpaint)
$x_t$	Generated noisy image at timestep $t$
$x_t^g$	Ground truth with $t$-level noise added
$\bar{\alpha}_t$	Noise schedule parameter (defines noise level)
$\beta_t$	Noise variance at step $t$
$\mu_\theta, \sigma_\theta$	Model-predicted mean and std
$\epsilon$	Gaussian noise ~ $\mathcal{N}(0, I)$

1. Task Definition

Problem: Image Inpainting

Fill missing regions in an image with realistic content.

Input & Output

Component	Notation	Shape	Description
Ground Truth (clean)	$x^g$	(1, 3, 256, 256)	Original clean RGB image, normalized to [-1, 1]
Mask	$m$	(1, 3, 256, 256)	Binary: 1 = keep (known), 0 = inpaint (unknown)
Output	$x_0$	(1, 3, 256, 256)	Complete image with filled regions

Example

Input Image (x):      Mask (m):          Output (x_0):
┌─────────────┐    ┌─────────────┐     ┌─────────────┐
│   ╔═══╗     │    │   ╔═══╗     │     │   ╔═══╗     │
│   ║   ║ face│    │   ║ 0 ║ keep│     │   ║ ✓ ║ face│
│   ╚═══╝     │    │   ╚═══╝     │     │   ╚═══╝     │
└─────────────┘    └─────────────┘     └─────────────┘
                    center missing      center filled!

---

2. Pre-trained Diffusion Model

What is it?

A neural network (UNet) trained to remove noise from images.

Training (already done, we just use the pre-trained model):

• Take clean images → add noise progressively → train model to denoise

Key Point: The model is unconditional (trained only for denoising, NOT for inpainting)

Model Interface

INPUT:
  - x_t: Noisy image at timestep t, shape (1, 3, 256, 256)
  - t: Timestep (scalar), range [0, 250]
       Higher t = more noise

OUTPUT:
  - 6 channels: (1, 6, 256, 256)
    • Channels 0-2: Mean prediction
    • Channels 3-5: Variance prediction

  These are processed to get:
    μ_θ(x_t, t): Mean of p(x_{t-1} | x_t)
    σ_θ(x_t, t): Std of p(x_{t-1} | x_t)

How to Use It

Sample one denoising step: $x_t \to x_{t-1}$

\[x_{t-1} = \mu_\theta(x_t, t) + \sigma_\theta(x_t, t) \cdot \epsilon, \quad \epsilon \sim \mathcal{N}(0, I)\]

Noise Schedule: $\bar{\alpha}_t$

Pre-computed values that define noise level at each timestep:

• At $t=0$: $\bar{\alpha}_0 \approx 1$ → clean image
• At $t=250$: $\bar{\alpha}_{250} \approx 0$ → pure noise

Usage: Add $t$-level noise to clean ground truth image: \(x_t^g = \sqrt{\bar{\alpha}_t} \cdot x^g + \sqrt{1-\bar{\alpha}_t} \cdot \epsilon\)

---

UNet Architecture (Brief Background)

The diffusion model uses a UNet - a U-shaped convolutional neural network.

Structure:

Input (256×256×3) + Timestep t
        ↓
    [Encoder: Downsample]
    256×256 → 128×128 → 64×64 → 32×32 → 16×16
    channels increase: 256 → 512 → 1024
        ↓
    [Bottleneck: Process at lowest resolution]
    16×16 with 1024 channels
        ↓
    [Decoder: Upsample]
    16×16 → 32×32 → 64×64 → 128×128 → 256×256
    channels decrease: 1024 → 512 → 256
        ↓
Output (256×256×6)

Skip connections: Encoder ═══════► Decoder
                  (preserve details)

Key Components:

• ResBlocks: Residual blocks that learn to denoise, conditioned on timestep $t$
• Attention: Self-attention at certain resolutions (32×32, 16×16, 8×8) to focus on important regions
• Skip connections: Copy features from encoder to decoder to preserve fine details
• Timestep embedding: Converts timestep $t$ into a vector that tells each layer “how much noise to remove”

Why U-shape: Downsample to capture global context → process → upsample to reconstruct details.

---

3. RePaint Algorithm

Core Innovation

Use the unconditional pre-trained model for inpainting by conditioning at each denoising step

Two key techniques:

1. Blend ground truth at each step (with correct noise level)
2. Resample multiple times (jump back and denoise again)

---

3.1 Key Technique 1: Conditioning with Ground Truth

The Problem

At timestep $t$:

• Unknown regions ($x_t$): generated from noise, have noise level $t$
• Known regions: should come from clean ground truth $x^g$

Challenge: Can’t mix clean $x^g$ with noisy $x_t$ — different noise levels!

The Solution

Step 1: Add noise to ground truth

Add $t$-level noise to clean ground truth $x^g$ to match the noise level of $x_t$:

\[x_t^g = \sqrt{\bar{\alpha}_t} \cdot x^g + \sqrt{1-\bar{\alpha}_t} \cdot \epsilon\]

Now $x_t^g$ (noisy ground truth) has the same noise level as $x_t$ (generated noisy image).

Step 2: Blend with mask

\[x_t^{\text{input}} = m \cdot x_t^g + (1-m) \cdot x_t\]

• $m \cdot x_t^g$: Known regions from noisy ground truth
• $(1-m) \cdot x_t$: Unknown regions from generation

Step 3: Denoise with model

\((\mu_\theta, \sigma_\theta) = \text{model}(x_t^{\text{input}}, t)\) \(x_{t-1} = \mu_\theta + \sigma_\theta \cdot \epsilon'\)

---

3.2 Key Technique 2: Resampling

The Problem

Even with correct noise levels, a single denoising pass may produce:

• Visible seams at boundaries
• Poor harmony between known and unknown regions

The Solution: Jump Forward and Denoise Again

Resampling process:

1. Denoise: $x_t \to x_{t-1} \to … \to x_{t-10}$
2. Jump forward (add noise back): $x_{t-10} \to … \to x_t$
3. Denoise again: $x_t \to x_{t-1} \to … \to x_{t-10}$
4. Repeat 10 times

Parameters (from config):

jump_length: 10        # Jump 10 steps forward
jump_n_sample: 10      # Repeat 10 times

Schedule pattern at t=240:

Timestep sequence:
240 → 241 → 242 → ... → 250 → 249 → ... → 240 → 241 → ...
 ↓     ↑                 ↑     ↓            ↓     ↑
denoise  jump forward        denoise back   denoise  jump again

Repeat 10 times before continuing to t=239

Why it works: Each cycle gives the model another chance to harmonize the regions.

Analogy: Like a painter who:

• Paints → blurs everything → paints again → blurs again
• Each cycle makes the blend smoother

Add Noise Formula

Jump forward $x_{t-1} \to x_t$:

\[x_t = \sqrt{1-\beta_t} \cdot x_{t-1} + \sqrt{\beta_t} \cdot \epsilon\]

---

4. Summary

Pipeline

Input: $x^g$ (clean ground truth), $m$ (mask)

Step 1: Initialize $x_{250} \sim \mathcal{N}(0, I)$

Step 2: Generate schedule with jump points at $t = 0, 10, 20, …, 240$

Step 3: For each $(t_{\text{last}}, t_{\text{cur}})$ in schedule:

• If $t_{\text{cur}} < t_{\text{last}}$ (Denoise):
  1. $x_t^g = \sqrt{\bar{\alpha}_t} \cdot x^g + \sqrt{1-\bar{\alpha}_t} \cdot \epsilon$
  2. $x_t^{\text{input}} = m \cdot x_t^g + (1-m) \cdot x_t$
  3. $(\mu_\theta, \sigma_\theta) = \text{model}(x_t^{\text{input}}, t)$
  4. $x_{t-1} = \mu_\theta + \sigma_\theta \cdot \epsilon’$
• If $t_{\text{cur}} > t_{\text{last}}$ (Resample):
  1. $x_t = \sqrt{1-\beta_t} \cdot x_{t-1} + \sqrt{\beta_t} \cdot \epsilon$

Output: $x_0$ (final inpainted image)

---

The Innovation

Use unconditional pre-trained diffusion models for inpainting by:

1. Conditioning: At each denoising step, blend noisy ground truth into known regions
2. Resampling: Jump forward and denoise again (10 times) to improve harmony

The Formula

At each timestep $t$:

\[x_t^{\text{conditioned}} = m \cdot \underbrace{(\sqrt{\bar{\alpha}_t} \cdot x^g + \sqrt{1-\bar{\alpha}_t} \cdot \epsilon)}_{x_t^g: \text{ noisy ground truth}} + (1-m) \cdot \underbrace{x_t}_{\text{generated noisy image}}\]

This ensures both regions have matching noise levels.

Three Steps to Remember

1. Add noise to clean ground truth $x^g$ to get $x_t^g$ at noise level $t$
2. Blend known regions (from $x_t^g$) and unknown regions (from $x_t$)
3. Denoise with pre-trained model

Repeat with resampling for better results!

---

Callback to Problem

Basically, we have formulated the tabular learning problem analogy in the image inpainting problem.

the inpainting algorithm part introduced in this paper (two key technique: conditioning & resampling ) we can directly transfer to the tabular data domain (including missing value imputation / regression or classification tasks).

However, the main problem is there is no pre-trained diffusion model in tabular learning domain

Additionally, the pre-trained diffusion model in this paper has another constrain, the width / height of generate image is fixed (e.g., 256x256), which should be a limitation for tabular data with varying feature dimensions and row lengths, if there is a diffusion model in tabular domain.
