This note is generated and formalized by claude code as a research assistant agent. We discussed about the numerical feature encoding problem.
1. Data Types in Tabular Learning
In tabular data, features can be categorized into two types with fundamentally different mathematical properties:
| Feature Type | Mathematical Structure | Example | What Matters |
|---|---|---|---|
| Categorical | Nominal set | Color ∈ {red, blue, green} | Distinguishability only |
| Numerical | Ordered field (ℝ) | Age ∈ {25, 30, 35} | Magnitude + Order |
Key difference:
- Categorical: Only equality matters. “red ≠ blue” is all we need to know.
- Numerical: Order and distance matter. “25 < 30 < 35” and “|30-25| < |35-25|” are meaningful.
Consider a toy dataset with two features:
| Sample | Color (categorical) | Age (numerical) |
|---|---|---|
| 1 | red | 25 |
| 2 | blue | 30 |
| 3 | red | 45 |
Step 1: Categorical encoding (ordinal encoder)
Color: red → 1, blue → 0
Step 2: Unified linear embedding
All values (categorical and numerical) are treated as scalars and mapped through a shared linear layer:
\[f(x) = Wx + b, \quad W \in \mathbb{R}^{128}, \quad b \in \mathbb{R}^{128}\]Note: Preprocessing (normalization/standardization) may be applied but is omitted here for simplicity.
Embeddings:
Color column: $f(0) = b$, $f(1) = W + b$
Age column: $f(25) = 25W + b$, $f(30) = 30W + b$, $f(45) = 45W + b$
Requirements:
- Categorical (Color): Need $f(0) \neq f(1)$ ✓ Achieved if $W \neq 0$
- Numerical (Age): Need $f(25) < f(30) < f(45)$ and $|f(30)-f(25)| < |f(45)-f(25)|$
- Question: Are these implicit information in different types of data guaranteed?
2. Why Value Proximity Matters for In-Context Learning
From Order to Proximity
Numerical data has a fundamental property: order induces proximity.
On the number line, values close to each other are considered similar:
\[\text{Position nearness} \iff \text{Value similarity}\]For example: $25$ is more similar to $30$ than to $45$ because $|30 - 25| < |45 - 25|$.
This proximity concept is structural—it comes from the mathematical nature of numerical data, not from any specific dataset.
ICL Requires Proximity-Based Attention
ICL prediction mechanism: For test sample with feature value $x_{\text{test}}$:
\[\hat{y}_{\text{test}} = \sum_{i=1}^{n} \alpha_i y_i, \quad \text{where } \alpha_i \propto \text{attention}(x_{\text{test}}, x_i^{\text{train}})\]Smoothness assumption: For numerical features, conditional label distribution is smooth:
\[|x_1 - x_2| \text{ small} \implies p(y | x_1) \approx p(y | x_2)\]This holds for many real-world relationships (age→income, temperature→failure rate, etc.).
Implication: For effective ICL, attention weights should respect value proximity:
\[|x_i - x_{\text{test}}| < |x_j - x_{\text{test}}| \implies \alpha_i > \alpha_j\]In other words: value proximity in 1D should translate to attention similarity in the model.
For categorical data, we just distinguish two different value is enough.
For numerical data, we need to more fine-grained encoding to preserve this promixmity.
3. Current Encoding Limitation
The Problem
Standard embedding $f(x) = Wx + b$ maps 1D values to high-dimensional space $\mathbb{R}^d$.
Question: Does attention similarity in $\mathbb{R}^d$ respect the original value proximity in 1D?
Analysis
Attention similarity is computed as:
\[\text{sim}(f(x_1), f(x_2)) = f(x_1)^\top f(x_2)\]Substituting $f(x) = Wx + b$:
\[\begin{align} \text{sim}(f(x_1), f(x_2)) &= (Wx_1 + b)^\top (Wx_2 + b) \\ &= x_1 x_2 \|W\|^2 + (x_1 + x_2) W^\top b + \|b\|^2 \end{align}\]Key observation: Similarity depends on:
- Product $x_1 x_2$ (not distance $|x_1 - x_2|$)
- Sum $x_1 + x_2$ weighted by arbitrary $W^\top b$
- Constant offset $|b|^2$
Counterexample
Consider three values: $x_1 = 1, x_2 = 2, x_3 = 100$
Value proximity: $|x_2 - x_1| = 1 < 99 = |x_3 - x_1|$ (so $x_2$ is much closer to $x_1$)
Attention similarity: \(\begin{align} \text{sim}(f(x_1), f(x_2)) &= 1 \cdot 2 \|W\|^2 + 3 W^\top b + \|b\|^2 = 2\|W\|^2 + 3W^\top b + \|b\|^2\\ \text{sim}(f(x_1), f(x_3)) &= 1 \cdot 100 \|W\|^2 + 101 W^\top b + \|b\|^2 = 100\|W\|^2 + 101W^\top b + \|b\|^2 \end{align}\)
If $W^\top b$ is large and positive, $\text{sim}(f(x_1), f(x_3))$ can be much larger than $\text{sim}(f(x_1), f(x_2))$, despite $x_3$ being far from $x_1$.
Conclusion
No architectural guarantee that:
\[|x_i - x_{\text{test}}| < |x_j - x_{\text{test}}| \implies \text{sim}(f(x_i), f(x_{\text{test}})) > \text{sim}(f(x_j), f(x_{\text{test}}))\]The mapping from value proximity (1D structure) to attention similarity (model behavior) is broken.
4. TabICL’s Column-Wise Module
TabICL uses a three-stage architecture. Our proposal targets Stage 1: Column-wise Embedding, where each feature column is processed independently using Set Transformer.
Column-wise processing:
\[\begin{align} \text{features} &= \text{Linear}(\text{raw\_values}) \quad \in \mathbb{R}^{B \times T \times 128} \\ \text{context} &= \text{SetTransformer}(\text{features}) \\ \text{weights}, \text{biases} &= \text{Linear}(\text{context}) \\ \text{embeddings} &= \text{features} \odot \text{weights} + \text{biases} \end{align}\]Key property: Set Transformer is permutation-invariant. It treats $[25, 30, 45]$ and $[45, 25, 30]$ identically, designed to capture distributional statistics independent of order.
Implication: For numerical columns, the proximity information (induced by order) is not explicitly encoded in the attention mechanism.
5.Proposal: Value-Based Position Encoding with RoPE
Core Idea
Add value-based inductive bias through RoPE to explicitly encode proximity in column-wise attention.
Instead of relying on learned embeddings to capture value proximity, we propose to inject proximity information explicitly through value-based encoding in the attention mechanism for numerical column.
Key insight: This is not traditional “positional encoding” (which encodes sequence position). Rather, it’s an explicit inductive bias that encodes the proximity structure inherent in numerical data—bridging value nearness (1D) to attention similarity (model).
Proposed Method
Type-Aware Column Processing
| Column Type | Processing Strategy | Rationale |
|---|---|---|
| Numerical | Value-based RoPE in Set Transformer | Encode proximity relationships |
| Categorical | Standard Set Transformer (no RoPE) | Order is meaningless |
Value Normalization
Normalize values to common range before using as positions:
\[p(x) = \frac{x - x_{\min}}{x_{\max} - x_{\min}}\]where $x_{\min}, x_{\max}$ are column minimum and maximum.
Properties:
- Maps to $[0, 1]$ range (scale-invariant)
- Preserves relative distances: $|p(x_2) - p(x_1)| \propto |x_2 - x_1|$
- Efficient: $O(n)$ computation
RoPE with Value-Based Positions
Standard attention:
\[\text{Attention}(Q, K, V) = \text{softmax}\left(\frac{QK^\top}{\sqrt{d}}\right) V\]Value-aware attention:
\[\begin{align} Q', K' &= \text{RoPE}(Q, K, \text{positions}=p(\text{values})) \\ \text{Attention}(Q', K', V) &= \text{softmax}\left(\frac{Q'K'^\top}{\sqrt{d}}\right) V \end{align}\]Attention weight between samples $i$ and $j$ depends on:
- Content similarity: $Q_i \cdot K_j$ (learned)
- Value proximity: RoPE bias based on $|p(x_i) - p(x_j)|$ (explicit)
Temperature Scaling (Optional)
\[\theta_{ij} = \frac{p(x_i) - p(x_j)}{\tau}\]where $\tau$ is learnable. Higher $\tau$ → weaker bias; lower $\tau$ → sharper distance-based attention.
6. Evaluation
Claim 1: Explicit Encoding of Partial Order
Statement: Value-based RoPE explicitly encodes partial order in attention mechanism.
Justification:
Standard attention: $A_{ij} \propto \exp\left(\frac{Q_i \cdot K_j}{\sqrt{d}}\right)$
RoPE attention: $A_{ij} \propto \exp\left(\frac{Q’i \cdot K’_j}{\sqrt{d}}\right)$ where $Q’, K’$ are rotated by $\theta{ij} \propto \text{pos}_i - \text{pos}_j$
With $\text{pos}_i = p(\text{value}_i)$:
\[\theta_{ij} \propto p(\text{value}_i) - p(\text{value}_j) \propto \text{value}_i - \text{value}_j\]Effect: Attention weight $A_{ij}$ biased by value difference. Small $|\text{value}_i - \text{value}_j|$ → higher attention.
Conclusion: Order relationship explicitly encoded in geometry, not learned from data.
Claim 2: Compatibility with In-Context Learning
Statement: Value-based encoding aligns with ICL’s similarity-based reasoning.
Justification:
ICL principle: $\hat{y}{\text{test}} \approx \sum_i \alpha_i y_i$ where $\alpha_i \propto \text{similarity}(x{\text{test}}, x_i^{\text{train}})$
Under smoothness assumption $p(y|x_1) \approx p(y|x_2)$ when $|x_1 - x_2|$ small:
- Training samples with values close to test sample should have higher $\alpha_i$
- Value-based RoPE implements this via attention bias
- Provides structural inductive bias aligned with ICL
Related work: Positional encodings improve performance in vision (spatial) and language (sequential) transformers.
7. Summary
The Core Problem
Proximity structure is lost in the mapping from values to attention in numerical data
Numerical data has a fundamental property: order induces proximity. On the number line, position nearness = similarity.
For ICL, this proximity should translate to attention similarity (smoothness assumption: nearby values → similar labels).
Current gap: Standard embedding $f(x) = Wx + b$ maps to $\mathbb{R}^d$, but attention similarity $f(x_1)^\top f(x_2)$ depends on value product $x_1 x_2$, not proximity $|x_1 - x_2|$.
Consequence: No architectural guarantee that value proximity → attention similarity.
Add value-based inductive bias through RoPE to explicitly encode proximity.
Method:
- Normalize: $p(x) = \frac{x - x_{\min}}{x_{\max} - x_{\min}}$
- Type-aware processing:
- Numerical: Apply RoPE with $\text{positions} = p(\text{values})$
- Categorical: Standard Set Transformer
- Effect: Attention bias based on $|p(x_i) - p(x_j)|$ (proximity-aware)
Key distinction: Not traditional positional encoding—explicit inductive bias bridging value proximity (1D structure) to attention similarity (model behavior).
Central Insight: For numerical features in tabular foundation models, order induces proximity, and proximity should translate to attention similarity. This structural mapping should be explicitly encoded, not implicitly learned.
