Cheetsheet for Model FLOPs and Memory estimation in training and inference mode.
The single mental shift from inference to training:
- inference frees activations (X) immediately;
- training must keep activations (X) alive for the backward pass, and additionally carry gradients and optimizer state in GPU memory.
1. Setup: a Transformer feed-forward block
Built around a Transformer-style feed-forward (FFN) block. A feed-forward block is two stacked linear layers (biases dropped for simplicity). The input and output both live in the model’s residual width D, with a wider hidden dimension F in between — exactly the $W_\text{in}$ / $W_\text{out}$ pair from the scaling chapter:
| Tensor | Role | Shape |
|---|---|---|
X |
block input (activations) | [B, D] |
W_in |
up-projection | [D, F] |
H |
hidden activation (= layer-1 output = layer-2 input) | [B, F] |
W_out |
down-projection | [F, D] |
Y |
block output (same width as input) | [B, D] |
B is the batch (number of tokens), D = d_model, F = d_ff (typically F ≈ 4D). Because input and output share the width D, blocks like this stack cleanly into a deep residual network.
This is the inference computation; training adds a backward pass and optimizer state on top.
A real FFN has a nonlinearity between the two matmuls (
H = σ(X W_in)). It’s an elementwise op — cheap in FLOPs, and in the backward pass it just multiplies the incoming gradient byσ'. We omit it here so the matrix algebra stays clean.
2. Forward pass
Two matmuls, one per layer:
\[H_{bj} = \sum_i X_{bi} (W_\text{in})_{ij} \qquad Y_{bk} = \sum_j H_{bj} (W_\text{out})_{jk}\]FLOPs. Each output element is a dot product (one multiply + one add ≈ 2 ops per term):
The block has P = DF + FD = 2DF parameters, so forward = 4BDF = 2BP
<2 FLOPs per parameter per token>.
The key fork — inference vs training.
- In pure inference you compute
Y, pass it on, and throwXandHaway. - In training you cannot discard them, because the backward pass needs them (see below).
3. Matrix-calculus background
The loss L is a scalar at the end. Backprop hands each layer the gradient of the loss w.r.t. its output, with the same shape as that output. Each layer must produce:
dW = ∂L/∂W— to update that layer’s weight.dX = ∂L/∂X— the gradient w.r.t. its input, to hand to the previous layer so the chain rule can continue.
Take a generic single matmul $Y = X W$. From the scalar chain rule, tracking indices ($Y_{bj} = Σ_i X_{bi} W_{ij}$):
\[\frac{\partial L}{\partial W_{ij}} = \sum_b \frac{\partial L}{\partial Y_{bj}} \frac{\partial Y_{bj}}{\partial W_{ij}} = \sum_b X_{bi}\, dY_{bj} = (X^\top dY)_{ij}\] \[\frac{\partial L}{\partial X_{bi}} = \sum_j \frac{\partial L}{\partial Y_{bj}} \frac{\partial Y_{bj}}{\partial X_{bi}} = \sum_j dY_{bj}\, W_{ij} = (dY\, W^\top)_{bi}\]So the two backward rules (can be used directly) for any linear layer are:
\[\boxed{dW = X^\top\, dY} \qquad\qquad \boxed{dX = dY\, W^\top}\]Two intuitions worth memorizing:
- Shape-matching gives the answer.
dWmust matchW, anddXmust matchX. Given the tensors on hand (X,W,dY), there’s essentially only one way to transpose-and-multiply them into the right shape. - To get a weight’s gradient, contract the two tensors around it.
dW = Xᵀ dYsums over the batch dimensionB: every token contributes to every weight’s gradient. That sum overBis exactly why, in data parallelism, gradients must be AllReduced across chips (each chip saw different tokens).
4. Backward pass (applying the rules to the block)
Start from dY = ∂L/∂Y and apply the two rules above to each layer, walking backward.
Down-projection (inputs H, W_out; incoming grad dY):
\(dW_\text{out} = H^\top\, dY \qquad\qquad dH = dY\, W_\text{out}^\top\)
Up-projection (inputs X, W_in; incoming grad is dH):
\(dW_\text{in} = X^\top\, dH \qquad\qquad dX = dH\, W_\text{in}^\top\)
The chain is the whole point:
\[dY \;\xrightarrow{\text{down-proj}}\; dH \;\xrightarrow{\text{up-proj}}\; dX\]Each layer uses the incoming gradient to compute its own weight gradient, and passes a gradient further back via dX = dY Wᵀ. Here dH is consumed (the bridge between the two layers); the final dX (shape [B, D], same as X) is what flows into the previous block in a deep network.
FLOPs. Each layer’s backward is two matmuls (dW and dX), each the same size as that layer’s forward matmul:
| Quantity | Formula | FLOPs |
|---|---|---|
dW_out |
Hᵀ dY |
2BDF |
dH |
dY W_outᵀ |
2BDF |
dW_in |
Xᵀ dH |
2BDF |
dX |
dH W_inᵀ |
2BDF |
So backward = 8BDF = 2× forward ≈ 4BP. Combined:
This is the “6ND” rule: training a model with N parameters on D tokens costs roughly 6ND FLOPs.
Crucial consequence for memory. dW_out = Hᵀ dY needs H, and dW_in = Xᵀ dH needs X. So both activations must survive from the forward pass until the backward pass reaches them. Generalize to L layers and you retain one activation tensor per layer —which is exactly why activation memory scales with batch B and depth L, and why gradient checkpointing (recomputing H instead of storing it) is the standard escape hatch.
5. What lives in GPU memory in training
For the block (P = 2DF parameters):
| Item | Size | Bytes | Scales with |
|---|---|---|---|
Params W_in,W_out |
2DF |
2 (bf16) | model |
| Grads | 2DF |
2–4 | model |
Adam m |
2DF |
4 (fp32) | model |
Adam v |
2DF |
4 (fp32) | model |
Activations X,H |
B·(D+F) |
2 (bf16) | batch B |
- Parameters, Gradients, Optimizers depend only on the model architecture, never on batch size.
- Activations scale with
B. StackLlayers and a batch of millions of tokens, and this row blows up to terabytes while the other rows stay in the tens of GB.
6. Summary
For a feed-forward block with D = d_model, F = d_ff, P = 2DF, batch B:
- Forward
H=XW_in,Y=HW_out·2BPFLOPs · retainX, H - Backward
dW=XᵀdY,dX=dYWᵀ·4BPFLOPs · chaindY→dH→dX - FLOPs ≈
6 · params · tokens=12BDF/block - Memory
8DF(fixed) +2·B·(D+F)activations (dominant)
Everything in large-scale training why data parallelism shards activations; why FSDP also shards the fixed model block; why gradient checkpointing exists: falls out of these two facts:
- keep activations alive for backward
- carry gradients + optimizer state.
